Tips and Tricks - Previews

Tips and Tricks - Previews

April 01, 06

The previews available for the Catia V5, SolidWorks and UG interfaces have been so successful that we have decided to develop a similar tool for users of the Pro-E converters.

To get a quick look at a part, choose a preview version.

Screenshot

The preview version displays the model in wireframe mode so that you can take a look it dynamically from every viewpoint.

Capture

When you have checked it you can open the full model with all the semantic information.

Screenshot
